Storage

At the end of each season

  • Clean the machine thoroughly.

  • Rinse the spray circuit.

  • Drain all crankcases and refill with new oil.

  • Check general lubrication of the machine.

  • Grease the cylinder rods in contact with the outside.

  • Check that all nuts and screws are tight.

  • Make all necessary paint touch-ups.

  • Replace worn or damaged parts immediately with original Ecorobotix parts.

  • Remove and respect the PTO shaft maintenance.

  • Store the tablet in a dry and dust-free place.

  • Store the machine in a dry place, protected from the weather.


Freeze protection of the machine

Never spray or apply antifreeze solution to the environment.


Do not winterize with liquid nitrogen.



Option 1


  1. Flush the spray circuit.

  2. Empty the tanks completely.

  3. Completely empty the boom through the end-of-boom drain valve (optional).

  4. Store the machine in a frost-free place.

Option 2


  1. Fill the rinse tank with 50 to 100 litres | 13 to 26 US gal of antifreeze solution.

  2. Let the antifreeze solution circulate throughout the spray circuit.

  3. Spray the antifreeze solution onto a watertight floor where the antifreeze solution can be recovered.


At the beginning of each season

  • Read the instruction manual carefully.

  • Check the general lubrification of the machine.

  • Wipe grease from the cylinder rods.

  • Check that all nuts and screws are tight.

  • Check that all protection equipment is in place and in good condition.

  • Flush the spray circuit.

  • Check the end-of-season points of the Periodicity table (Periodicity table).
