Safety
INFORMATION
Before using the machine and putting this manual into practice, the user must have read the entire user manual, especially the chapters:
-
Safety
-
Kinematic and dynamic limits
-
Location and meaning of pictograms
CAUTION
To stop spraying, deactivate the Spraying mode on the app by clicking on it once.
Prerequisites
-
Check that the necessary PPE for working with plant protection products is available and functional.
-
Check the pressure of the machine’s tires (1.5 bar | 21.7 psi).
-
Make sure that the working surface is horizontal and flat.
Equipment:
-
1 ruler of 20 or 30 cm | 7.87 or 11.81 in
-
1 open-end wrench 17 mm | 0.67 in
-
1 beaker 300 ml | 10.14 fl oz
-
1 beaker 3 L | 0.66 gal
-
1 clean cloth
-
Cleaning liquid for windows
In this chapter:
-
Sprayer hitching -
Tank system hitching -
Starting the control system -
Getting started with the tablet -
Adjusting the working pressure -
Nozzle check -
Mixture preparation (3.0, 4.0 & 4.1) -
Agitation -
Checks before road transport -
In the field -
Surface treatment -
Cleaning after treatment interruption -
Cleaning after treatment (3.0, 4.0 & 4.1) -
Storing the sprayer
